600 Meter Band Viewer at W5JGV - WD2XSH/7

Please press the "F11" key to maximize your sceeen size.

600 Meter Band as seen at W5JGV

Please refer to the color chart legend for signal strength.

Receiver is a SoftRock Lite II SDR board modified for 600 Meters by Tony, KB9YIG. The decoder software is SPECTRUM LABORATORY. The antenna is a vertical whip antenna 9 feet long with a preamplifier driving 250 feet of RG-6 coaxial cable.

This page auto-refreshes every 5 minutes.

A new capture frame is uploaded to the web server every five minutes when the system is running. Please check the date and time stamp on the picture, as this system may be offline at any time. It will normally be offline during daylight hours, because I am upstream data volume limited on a 30 day cycle by my ISP. Occasionally, rain storms will shut down my satellite uplink to the internet, temporarily preventing new frames from being uploaded to the server.
